Audio Implements

  Audio Implements is a manufacturer of specialist in ear monitoring earpieces for on air broadcast host applications, used by major television stations worldwide. The range is also suitable for security and outside sports applications where the wearer requires high quality, comfort and clarity of communications. The ear pieces, transducers and cable sets are designed for left or right ear fitment and a full range of ear tip sizes are available to ensure secure and comfortable wearing. The clarifier tube design tailors the audio frequency response to be full bandwidth at the entry point and dispenses with the need for heavy transducers within the ear area. The system is visually transparent in face on shots permitting the host to be in touch with the control room at all times without impairing the on-air presentation.





 IFB Accessories             Cords                         Receivers                        Audio Clarifiers





On-Camera Audio Clarifiers with eartips

The On-Camera Audioclarifier with assorted ear tips is mostly used for guest talent. It comes with seven different size ear tips that can be quickly changed to fit different size ears. Both the custom and tip models are also used for security and surveillance work. If you have a darker skin tone, just choose "TINT" after the order number and we will attach a darker tinted tube to the order in place of a light flesh tone color.

Cat# Description

161 OTCS-R On-Camera Audioclarifier with ear tips, coiled acoustic tube and single receiver clip, right ear

162 OTCS-L On-Camera Audioclarifier with ear tips, coiled acoustic tube and single receiver clip, left ear

163 OTSS-R On-Camera Audioclarifier with ear tips, straight acoustic tube and single receiver clip, right ear

164 OTSS-L On-Camera Audioclarifier with ear tips, straight acoustic tube and single receiver clip, left ear

166 OCS-R On-Camera Audioclarifier with coiled acoustic tube and single receiver clip, right ear (no tips included)

167 OCS-L On-Camera Audioclarifier with coiled acoustic tube and single receiver clip, left ear (no tips included)

168 OSS-R On-Camera Audioclarifier with straight acoustic tube and single receiver clip, right ear (no ear tips included)

169 OSS-L On-Camera Audioclarifier with straight acoustic tube and single receiver clip, left ear (no ear tips included)

171 OTCD-R On-Camera Audioclarifier with ear tips, coiled acoustic tube and double receiver clip, right ear

172 OTCD-L On-Camera Audioclarifier with ear tips, coiled acoustic tube and double receiver clip, left ear

173 OTSD-R On-Camera Audioclarifier with ear tips, straight acoustic tube and double receiver clip, right ear

174 OTSD-L On-Camera Audioclarifier with ear tips, straight acoustic tube and double receiver clip, left ear



UNIVERSAL Audioclarifier

The UNIVERSAL Audioclarifier fits either ear and comes with one clarifier tube, clothing clip and seven assorted ear tips, catalogue #160.





Additional ear tips for On-Camera Audioclarifier - Model #161 to #174

571 OET-1 Ear tip, extra small

572 OET-2 Ear tip, small

573 OET-3 Ear tip, medium

574 OET-4 Ear tip, medium large

575 OET-5 Ear tip, large

576 OET-6 Ear tip, extra large

577 OET-A Accordion ear tip

599 MA-1 Replacement male adaptor for OET ear tips



Magnetic Receivers

All receivers have metal 1/4" nubbins and metal base for long life.

Impedance: 15, 125, 500, 200, 4.7k ohms

Sensitivity: 120/3dB SPL @ 1 kHz/mW

Frequency response: 20 Hz to 3500 Hz

Distortion: less than 1% at 1mW @ 1 kHz

Maximum power input: 100m

Cat# Description

301 PO-15 15 ohms

302 PO-125 125 ohms

303 PO-500 500 ohms

305 PO-2000 2000 ohms

307 PO-4.7k 4.7k ohms



Receiver Cords

High flex tinsel cord, 5' (1.52m) long, gray in color

Cat# Description

310 HDS-96 Cord with 3/32" (2.4mm) 90 degree sub-mini plug

311 HDS-2 Cord with 1/4" (6.3mm) standard plug

312 HDS-92 Cord with 1/8" (3.5mm) 90 degree mini plug

313 HDS-98 Cord with 1/8" (3.5mm) mini plug

314 HDS-95 Cord with 3/32" (2.4mm) sub-mini plug

338 HDS-97 Cord with 1/8" (3.5mm) diamond tip plug

(Pic NA)

315 HDC-2 Coiled cord with 1/4" (6.3mm) standard plug

316 HDC-92 Coiled cord with 1/8" (3.5mm) 90 degree mini plug

317 HDC-98 Coiled cord with 1/8" (3.5mm) mini plug

309 HDC-95 Coiled cord with 3/32" (2.4mm) sub mini plug

318 HDC-96 Coiled cord with 3/32" (2.4mm) 90 degree sub mini plug

337 HDC-99 Coiled cord with 1/8" Stereo 90 degree mini plug

387 HDK-98 Coiled cord with 1/8"Threaded TRS mini plug

319 HDY-98 Y-cord with 1/8" (3.5mm) mini plug 1' from ears to Y and 1' from Y to plug

330 VSS-15 Volume control cord, 15 ohms with 1/4" (6.3mm) standard plug

331 VSS-500 Volume control cord, 500 ohms with 1/4" (6.3mm) standard plug

332 VSS-2000 Volume control cord, 2000 ohms with 1/4" (6.3mm) standard plug

333 VSM-15 Volume control cord, 15 ohms with 1/8" (3.5mm) mini plug

334 VSM-500 Volume control cord, 500 ohms with 1/8" (3.5mm) mini plug

335 VSM-2000 Volume control cord, 2000 ohms with 1/8" (3.5mm) mini plug

350 CPC-1 Cord with 1/8" plug for cell phone

351 CPC-2 Cord with XLR plug for cell phone

352 CPC-3 Cord with 1/4" plug for Cell Phone





Audio Implements - CELL PHONE ACCESSORY FOR IFB



Part #420 Model #CP-200

This small push to talk box with belt clip can be used on most cellular phones, when it is important to prevent sound from coming into the microphone when you are not talking. This box is used with Model CPC-M6 ear cord with microphone, along with our PO-125 receiver.







Part #421 Model #CP201

This push to talk box has an amplifier for the increase in volume, often needed for IFB in noisy #161 or #162 areas. The box has 2 outputs, one sub-mini, (3/32") tip ring and sleeve for use with the CPC-M6 cord (mic and listen), or for listening only a mini (1/8") jack. It comes with a battery drawer for a 9V battery, low battery light and a switch to operate with or without amplifier. It also has a REACH style belt clip.





Part #423 Model #CP-201-A    NEW

NOW AVAILABLE FOR THE NEW IPHONE AND BLACKBERRY.

1/8" 4-conductor plug with 90 angle



Part #422 Model #CP-202

This box is for use with any device that has Bluetooth capability. It operates similar to the CP-201, but connects through Bluetooth . The red button answers and hangs up the incoming call and also toggles the microphone on and off. The box has 2 outputs, one sub-mini, (3/32") tip ring and sleeve for use with the CPC-M6 cord (mic and listen), or for listening only a mini (1/8") jack. It comes with a battery drawer for a 9V battery , status pilot light. It also has a REACH style belt clip.



Part #355 Model #CPC-M6

CELL PHONE EAR CORD W/MIC. Ear cord with microphone is used in the ENG field for IFB over a cell phone, along with a PO-125 (125 ohm) receiver, part #302. It can plug directly into the phone or through the push to talk box, model #CP-200 or model #CP-201.
